Open frame model portable model with 4 wheels ensure easily moving; Also can
make silent type GLD7000ES, noise can cut down.
Product Description
1. Lower consumption , lower noise, lower pollution, Higher efficiency and
environmental friendly
2. Strict testing system, stable voltage and frequency
3. Secured ground terminal
4. Stronger automatic startup system, starting with in only 1~5s
5. Smart in size, delicate in style, longer service life
6. Very diversified and customized choices
Model
|
GLD7000R(E)
|
GENERATOR
|
Frequency (HZ)
|
50HZ
|
60HZ
|
Max.output (KW)
|
6.0
|
6.5
|
Rated output(KW)
|
5.5
|
6.0
|
Rated AC Voltage(V)
|
120,220,230,120/240,220/380
|
Power Factor ( cosφ)
|
1
|
DC output (V)
|
12V/8.3A
|
Phase
|
Single Phase or Three phase
|
Alternator Type
|
Self-excited,2-pole, Single phase alternator
|
Starting System
|
Recoil or Electric
|
Noise Level (Dba/7m)
|
80-85Db
|
Fuel Tank Capacity (L)
|
15
|
Continuous Running Time (hr)
|
6.5
|
5.9
|
ENGINE
|
Engine Model
|
GLD188FA
|
Engine Type
|
Single-cylinder, vertical,4-stroke air-cooled diesel engine, Direct
Injection
|
Bore〜Stroke (mm)
|
88〜75
|
Displacement (cc)
|
456
|
Fuel
|
0#(summer) or -10#(winter) light diesel oil,-35# (cold)
|
Rated output power [kw/rpm]
|
6.6/3000
|
7.3/3600
|
Lubrication Oil Volume (L)
|
1.65
|
Compression ratio
|
19:1
|
STANDARD FEATURES
|
Voltmeter
|
YES
|
AC Output Socket
|
2
|
AC Circuit Breaker
|
YES
|
Oil warning Light
|
YES
|
Oil Alert
|
YES
|
Wheel
|
4
|
OPTIONAL FEATURES
|
Dc circuit breaker
|
OPTIONAL
|
Running time meter
|
OPTIONAL
|
Big wheel
|
OPTIONAL
|
Three phase voltage
|
OPTIONAL
|
Current meter
|
OPTIONAL
|
ATS
|
OPTIONAL
|
Remote control
|
OPTIONAL
|
DIMENSIONS
|
Dimension(L*W*H)(mm)
|
750*500*640
|
Net Weight(kg)
|
107
|
|
